$37.99
|
Specification |
Details |
|
Product Name |
Renogy Wanderer Li 30A PWM Solar Charge Controller |
|
Focus Keyword |
30A PWM Solar Charge Controller for 12V Lithium Batteries |
|
Brand |
Renogy |
|
Charge Controller Type |
Pulse Width Modulation (PWM) Solar Charge Controller |
|
Rated Charging Current |
30 Amps High-Efficiency Solar Battery Charging |
|
Nominal Battery Voltage |
12V DC Solar Battery System |
|
Maximum Solar Panel Input Power |
Up to 400 Watts for 12V Solar Systems |
|
Maximum PV Input Voltage (Voc) |
25V DC Solar Input |
|
Battery Compatibility |
Lithium (LiFePO4), AGM, Gel, Flooded Lead-Acid, and Sealed Batteries |
|
Charging Technology |
Smart 4-Stage PWM Charging (Bulk, Boost, Float, Equalization for compatible batteries) |
|
Lithium Battery Mode |
Built-in Lithium Charging Profile for 12V LiFePO4 Battery Banks |
|
System Grounding |
Negative Ground Solar Charge Controller |
|
Self-Consumption |
Ultra-Low Power Consumption (Less than 10mA) |
|
Communication Port |
RS232 Port for Bluetooth Monitoring and Smart Connectivity |
|
Bluetooth Compatibility |
Compatible with Renogy BT-1 Bluetooth Module and Renogy DC Home App for Remote Monitoring |
|
Temperature Compensation |
Automatic Battery Temperature Compensation for Improved Charging Performance |
|
LED Indicators |
Multi-Color LED Charging Status, Battery Status, and Fault Indicators |
|
Load Control Modes |
5 Programmable Load Modes for Solar Lighting and DC Appliances |
|
Protection Features |
Overcharge Protection, Over-Discharge Protection, Reverse Polarity Protection, Short Circuit Protection, Overload Protection, Reverse Current Protection, Temperature Protection, Battery Over-Voltage Protection |
|
Operating Temperature |
-20°F to 113°F (-29°C to 45°C) |
|
Storage Temperature |
-31°F to 176°F (-35°C to 80°C) |
|
Maximum Wire Size |
Supports Up to 8 AWG Solar Cable |
|
Dimensions |
6.45 × 4.31 × 1.76 Inches |
|
Weight |
Approximately 0.65 lbs (0.29 kg) |
|
Recommended Applications |
Off-Grid Solar Systems, RV Solar, Camper Vans, Boats, Marine Solar, Cabins, Tiny Homes, Backup Power Systems, Solar Lighting, and DIY Solar Installations |
The Renogy Wanderer Li 30A supports 12V battery systems, 30A charging current, up to 400W solar input, multiple battery chemistries including lithium, and includes an RS232 communication port with optional Bluetooth monitoring via Renogy’s BT-1 module. It also provides 4-stage PWM charging and multiple built-in protection features.
